NGIMO 48V 1000W Rear Hub Motor Wheel Conversion Kit
Upgrade your bicycle with the INGIMO 48V 1000W Rear Hub Motor Conversion Kit, designed for riders looking for strong power, smooth acceleration and reliable everyday performance.
The gearless rear hub motor delivers up to 66 N·m of torque and is suitable for commuting, recreational riding and electric bicycle conversion projects.
Key Features
- 48V 1000W Rear Hub Motor
- Gearless Hub Motor Design
- Up to 66 N·m Max Torque
- Up to 55 km/h Top Speed under suitable test conditions
- Cassette compatible
- Supports up to 10-speed cassette
- 135±1 mm O.L.D
- 211 mm axle length
- IPX5 motor protection
- Noise level below 55 dB
- Motor efficiency above 82%
- Compatible with disc brakes
- Aluminum alloy wheel rim
- 36H × 12G spokes
Available Wheel Sizes
Available wheel configurations may include:
- 26"
- 27.5"
- 700C / 28" / 29"
20" configuration should only be listed if currently available.
Controller Specifications
- Rated Voltage: 48V
- Rated Current: 15A
- Max Current: 30A
- Low Voltage Protection: 39±1V
- Over Voltage Protection: 62.4V
Optional Components
Depending on configuration, optional components may include:
- LCD Display
- Headlight
- Taillight
- PAS Sensor
- Thumb Throttle
- Brake Levers
- Brake Sensors
- Battery
- Extension / E-BUS Cable
- Controller
- Charger
- Rear Rack Battery
PAS Sensor Options
Left-side and right-side PAS sensor options are available depending on the bicycle configuration.
Features may include:
- Double Hall 12 Magnets
- 3-Pin Male Connector
- IP65 Waterproof
- Easy Installation
Brake Options
The kit can be configured with:
- Mechanical Brake Levers
- Brake Sensors for compatible brake systems
Compatibility Notice
Please confirm your bicycle frame dimensions, dropout width, wheel size, cassette, brake system and connector requirements before ordering.
For customized configurations or bulk/OEM orders, please contact INDIGO VEHICLE / INGIMO before purchase.
